HKNC-500+5 axis CNC pob zeb txiav tshuab yog ib tug lej tswj choj pom nrog 5 interpolated axes, haum rau cov tuam txhab xav tau lub compact thiab yooj yim-rau-siv tshuab txiav slabs thiab txheej txheem me me blocks.
Nws yog tsim los ntawm cov hlau monobloc thav duab thiab cov khoom siv txheem, nrog rau ntau yam khoom siv uas tso cai rau cov txheej txheem ua haujlwm yuav tsum tau ua haujlwm thiab lub tshuab poob qis.
Nws raug pom zoo rau cov tsim khoom sib txawv ntawm cov khoom uas yog li xav tau ntau tshaj
yooj; Nws kuj tseem tuaj yeem tsim cov khoom 3D yooj yim los ntawm kev sib koom ua ke ntawm lub tshuab nrog CAD-CAM tshwj xeeb
software.
Hom kev ua haujlwm
Linear txiav: ntau, ua ke, sib npaug, oblique, inclined. Muaj cov kev pab cuam sib txawv los txiav cov slabs los tsim cov flooring, cov kauj ruam (ob lub duab plaub thiab trapeze-puab), qhov rais sills, skirting boards, thiab polygons.
Txiav ntawm tus qauv polygons: voj voog, duab plaub, arches, ellipses. Muaj ntau qhov sib txawv nrog cov duab ua ntej thiab txiav cov kev ua tiav.
Tshuab tshuab
Thaum cov duab tau teem rau ntawm lub slab, qhov kev txiav ua ntu tuaj yeem ua kom zoo dua. Nyob rau theem no hte overlapping txiav raug tshem tawm, kev sib tsoo cov txiav yog txiav, cov tsis tiav yog ua tiav nrog ib tug so machining, thiab txiav txiav yog optimized kom txo tau lub taub hau rotations thiab lub ceev ceev mus txawv tebchaws.
Cov neeg siv khoom Rhiav
Peb lub Hoobkas
Ntim & Chaw thau khoom
|
TECHNICAL DATA FOR HKNC-500 |
||
|
Txoj kab uas hla ntawm saw hniav |
ø400-ø500 |
mm |
|
Dimension ntawm kev ua haujlwm platform |
3300x2000 |
mm |
|
Max. txiav ntev |
3300 |
mm |
|
Max. txiav thickness |
140 |
mm |
|
Max. lifting stroke |
250 |
mm |
|
Max. nqa qhov hnyav los ntawm lub khob sunction |
200 |
kg |
|
Lub zog ntawm lub cev muaj zog |
11 |
kws |
|
Lub zog ntawm cutter ncej reciproctating lub cev muaj zog |
2 |
kws |
|
Lub zog ntawm crossbeam hloov lub cev muaj zog |
1.1 |
kws |
|
Lub zog ntawm qhov chaw nres tsheb hydraulic |
2.2 |
kws |
|
Lub zog ntawm lifting motor |
0.85 |
kws |
|
Lub zog tag nrho |
16 |
kws |
|
Kev siv dej |
2 |
m3/h |
|
Qhov hnyav tag nrho |
5400 |
kg |
|
Qhov Loj (L x W x H) |
5700x3260x2765 |
mm |
