Hualong MachineryHydraulic Lift Mulit-blade Pob zeb Thaiv Tej Tshuab HLDQ-1600yog tsim rau tej pob zeb blocks, xws li granite, marble.It yog txuam nrog trolley thiab khiav, uas yog ib tug zoo pab ntawm lub Hoobkas pob zeb.
Lub tshuab no yog optimized thiab txhim kho nyob rau hauv lub hauv paus ntawm cov tsooscombination saw. Nws yog cov khoom plaub-ncej (los yog rau-tus ncej) cov qauv, goodrigidity, me me qhov sib txawv, tsis cuam tshuam los ntawm kub expansion los yog txias contraction los ntawm lub sab nraud ib puag ncig, uas zoo txo lub co co nyob rau hauv cov txheej txheem txiav. Cov hniav ntu siv yog me me. Cov efficiency ntau lawm yog siab. Lub slab flatness yog zoo
Thawj plaub tus ncej, xauv cia rau tib lub sijhawm, kom lub tshuab, suav nrog lub tshuab hluav taws xob, lub cev muaj zog, lub thawv spindle thiab cov khoom siv ua kom tiav hauv lub xeev nruj thaum lub sijhawm txiav. Kev ruaj ntseg zoo zoo txuas ntxiv rau kev pab cuam life.txo lub zog noj thiab nce cov zis.
Roj-immersed lubrication, muaj cov roj puv puv nyob rau hauv qhov chaw nruab nrab ntawm plaub phau ntawv qhia ncej thiab lub ntsiab thav duab, thiaj li hais tias cov lus qhia pillarsguide lub tes tsho yuav tsum ib txwm lubricated, uas zoo heev prolong lub neej ntawm cov khoom .Qhov no yog ib tug tsawg peev thiab muaj peev xwm stoneblock txiav. tshuab
Lus Cim: Cov cav tov nrog qhov sib txawv txiav qhov siab thiab dav tuaj yeem hloov kho raws li cov neeg siv khoom xav tau.
Lub ntsiab nta
1) Tag nrho kaw plaub-lub tog raj kheej guider rail yog siv rau kev nce thiab poob uas ua rau tag nrho cov qauv ruaj khov, txo qis hnav thiab ua kom cov tshuab ua haujlwm zoo tshaj plaws rau lub sijhawm ntev.
2) Hluav taws xob tsis siv neeg hlais sib cais txhim kho qhov tseeb ntawm cov khoom, txo kev siv zog thiab txhim kho kev ua haujlwm.
| Thechincal Data | |||
| Qauv No. | HLDQ-1600/6 | HLDQ-1600/10 | HLDQ-1600/16 |
| Cov hniav loj diam & qty. | 1600mm - 3pcs | 1600mm - 5pcs | 1600mm - 8pcs |
| Cov hniav me me txoj kab uas hla & qty. | 940mm - 3 pcs | 940mm - 5pcs | 940mm - 8pcs |
| Hniav lifting stroke (mm) | 1000 | ||
| Max. txiav qhov loj (mm) | 3500x1300x950 | ||
| Lub zog ntawm lub cev muaj zog (kw) | 2.2 | ||
| Lub zog ntawm nqa lub cev muaj zog (kw) | 2.2 | ||
| Lub cev muaj zog (kw) | 37 | 45 | 55 |
| Lub zog tag nrho (kw) | 41.4 | 49.4 | 59.4 |
| Kev siv dej (m3 / min) | 37 | 42 | 42 |
| Qhov hnyav tag nrho (kg) | 6000 | 7800 | 8500 |
| Qhov Loj (L x W x H - mm) | 8500x4000x5500 | ||
Txoj cai nce
Sab laug elevation
Kev nce qib pem hauv ntej
CHANGCHAI siab zog cav
Imported EATON tswj valve
Nyiv Shimadzu hydraulic lub cev muaj zog
Txheej txheem ntau lawm:
-
Cov neeg siv khoom xav tau npaj lub hauv paus ua ntej nrog kev kos duab muab los ntawm peb.
-
Nruab lub tshuab thiab cov hniav.
-
Tshuab txiav.
-
Tshem tawm cov slab los ntawm thaiv ib qho los ntawm ib qho, peb tuaj yeem ua pwm los txhawb lub slab, tshuab tuaj yeem txiav ncaj qha mus rau qhov kawg thiab slab yuav tsis sib nrug.
-
Trolley muaj nyob rau hauv lub tshuab thiab kho raws li cov neeg siv khoom xav tau.
Cov neeg siv khoom qhov chaw
Lub tshuab dab tsi zoo rau marble thaiv txiav tshuab?
Rau kev txiav marble blocks, lub pob zeb diamond hlau pom tshuab yog suav tias yog ib qho kev xaiv zoo tshaj plaws vim nws muaj peev xwm txiav los ntawm cov ntaub ntawv nyuaj thiab ntom zoo li marble nrog precision thiab efficiency. Txawm li cas los xij, kuj tseem muaj lwm lub tshuab txiav uas tuaj yeem tsim nyog rau kev txiav cov pob zeb marble, nyob ntawm seb koj qhov kev xav tau tshwj xeeb. Nov yog qee cov cav tov feem ntau siv rau marble thaiv txiav:
Pob zeb diamond hlau saw tshuab: Pob zeb diamond hlau pom cov cav tov tshwj xeeb tsim los txiav cov pob zeb loj loj rau hauv cov slabs lossis cov duab tshwj xeeb. Lawv siv cov hlau nyias, pob zeb diamond-coated uas tuaj yeem txiav los ntawm marble nrog kev ua haujlwm siab, cov khib nyiab tsawg heev, thiab ua kom zoo nkauj.
Choj Saw: Choj saws yog cov tshuab txiav ntau yam uas feem ntau siv hauv kev ua pob zeb. Lawv muaj lub pob zeb diamond-tipped ncig hniav ntsia rau ntawm tus choj zoo li tus qauv uas txav hla lub pob zeb marble kom txiav ncaj. Choj saws yog qhov zoo tagnrho rau kev txiav cov pob zeb me me los yog tsim cov duab sib txawv thiab txiav.
CNC pob zeb txiav tshuab: CNC pob zeb txiav tshuab yog automated txiav tshuab uas siv computer numerical control (CNC) technology los tsim kom meej thiab complex txiav ntawm marble blocks. Lawv muab siab precision thiab repeatability, ua rau lawv haum rau kev cai tej yaam num los yog loj-scale ntau lawm.
Hlau Saw nrog Ncej System: Hom hlau pom tshuab no muaj cov qauv tsim uas tuav cov marble thaiv kom ruaj ntseg thaum txiav. Nws muaj kev ruaj ntseg thiab kev tswj hwm, tso cai rau kev txiav cov pob zeb loj thiab tuab.
Chain Saw Tshuab: Cov saw saw tshuab nruab nrog pob zeb diamond-tipped hniav kuj tuaj yeem siv rau kev txiav marble blocks. Lawv tsim nyog rau kev txiav ncaj thiab nkhaus hauv marble.
Thaum xaiv lub tshuab zoo tshaj plaws rau kev txiav marble blocks, xav txog yam xws li qhov loj thiab tuab ntawm cov blocks, txiav precision, ntim ntau lawm, thiab pob nyiaj siv. Tsis tas li ntawd, xyuas kom meej tias lub tshuab specifications ua raws li koj cov kev xav tau tshwj xeeb thiab cov chaw tsim khoom lossis cov chaw muag khoom muaj npe nrov thiab muab kev txhawb nqa zoo tom qab muag.
Yuav tsum ua raws li cov lus qhia kev nyab xeeb thaum ua haujlwm ntawm lub tshuab txiav thiab siv cov cuab yeej tiv thaiv tsim nyog kom muaj kev nyab xeeb ntawm cov neeg ua haujlwm thiab cov neeg ua haujlwm.
